Dash Size |
04 |
|
Hose ID Size |
1/4 in |
|
F Thread Dash Size |
04 |
|
F Thread Size (in. TPI) |
1/4-19 |
|
C Cut-Off Factor |
45.5 mm |
|
D Drop |
15.0 mm |
|
CH2 |
19 mm |
|
Weight Per Each |
0.17 lb |
|
Type |
45º BSPP Female 60º cone with O-Ring |
|
Bend Angle |
45 º |
|
Cone Angle |
60 º |
