The reliability and strength of the MEC is the result of continuous design and manufacturing improvements accomplished during 40 years of deployments.
It’s simple and practical design made the MEC pumps the product of reference for agricultural and municipalities septic applications.
• Forced lubrication, 4-ways valve, non-return check valve
• Available hoses connections: Ø 45 mm / Ø 60 mm / G 2”
• Thread for Overpressure valve: G 1”1/4
|
Max Rate of Flow |
(CFM) |
127 |
|
Max rpm |
(rpm) |
1400 |
|
Max Working Pressure |
Bar (PSI) |
2.5 (36) |
|
Max Vacuum % |
InHg |
92% (27.2") |
|
Power @ max vacuum |
kW (hp) |
7 (9.4) |
|
Net Weight |
lbs |
165 |
|
Dimensions *PUMP LENGTH IS FROM FRONT OF SHAFT* |
In (LxWxH) |
19 5/8x12 15/16x16 3/4 |
|
Oil Tank Capacity |
(l) |
1.2 |
