PN23 Vacuum Pump w/ 8HP Motor


PN23 Vacuum Pump w/ 8HP Motor
Item Number: 1181-0200-H
  Be the first to review this item
Unit Price:
$4,650.00
Quantity


Must be shipped via Freight! See our Freight Terms and Conditions HERE

Jurop PN23 Direct Drive Bolt and Go System Includes:

• PN23 Pump
• Premounted on Pump Stand
• No Need For PTO
• Electric Start Motor

8HP Electric Start Honda OHV Gasoline Engine:

• OHV Head Design
• Cast Iron Sleeve Cylinder
• Ball Bearing Crankshaft
• Automatic Oil Alert System Shuts Motor Down When Oil Is Low
• Low Vibration & Noise
• Low Maintenance
• Easy Starting

All Items Fully Assembled!

Jurop PN23 Pump Specifications:

The Jurop PN23 is an air cooled, sliding vane vacuum pump with forced lubrication and copper oil piping. This vacuum pump features aluminium inlet/outlet conveyors and built-in vacuum with pressure changeover valve.

• Version PN: 1 3/8" (1.375 in) Shaft Size
• Pump Drive Rotation: Counterclockwise (CCW) and Clockwise (CW) available
• 1.5" Connections
• Oil Tank Capacity - 1.27 Quart
• Injection-Air cooled
• RPM Range: 900 - 1300
• Maximum Air Flow: 92CFM @ free air, 74CFM @ 18 inHg (inches of Mercury)
• Maximum Intermittent Vacuum: 27.6"
• Maximum Intermittent Pressure: 21PSI
• Net Weight: 117 LBS
• Recommended Oil ISO 150

PN23 Tech Sheet viewable HERE
